Description: The Haas ST-10 CNC Lathe is a compact, high-performance turning center designed for precision machining of small to medium-sized parts. This machine is part of Haas Automation Inc.’s renowned ST series, known for its reliability, ease of use, and advanced capabilities in the field of CNC (Computer Numerical Control) machining.

What it is Used For: The Haas ST-10 CNC Lathe is used for a variety of turning operations, including cutting, threading, facing, and boring. It is commonly employed in industries such as aerospace, automotive, medical device manufacturing, and general machining, where precision and repeatability are critical.

Capabilities:

1. Compact Footprint:
   • The ST-10 has a small footprint, making it ideal for workshops with limited space while still offering substantial machining capabilities.
2. High Precision:
   • The CNC control system ensures high precision and repeatability, crucial for producing intricate parts with tight tolerances.
3. Powerful Spindle:
   • Equipped with a high-performance spindle capable of achieving high RPMs, enabling efficient machining of a variety of materials, including metals and plastics.
4. Rigid Construction:
   • Built with a robust cast-iron frame and high-quality components, the ST-10 provides stability and reduces vibrations during machining, ensuring accuracy and extending tool life.
5. Tool Turret:
   • Features a high-speed, servo-driven turret that can accommodate multiple tools, allowing for quick tool changes and reducing setup times.
6. Advanced Control System:
   • The Haas CNC control system offers an intuitive interface, real-time monitoring, and powerful programming capabilities, enhancing productivity and ease of use.
7. Automation Ready:
   • Can be integrated with automation solutions such as bar feeders and robotic loaders, increasing production efficiency and reducing manual labor.
8. Wide Range of Operations:
   • Capable of performing a variety of turning operations, including facing, threading, drilling, and boring, making it versatile for different applications.

Applications:

• Custom Fittings and Adapters:
  • Machining custom fittings and adapters for network cabling and connections within data centers.
• Precision Spacers:
  • Creating spacers and standoffs used to secure and organize equipment within server racks.
• Connector Housings:
  • Producing housings for connectors and other electronic interfaces used in data communication systems.
• Cable Management Accessories:
  • Machining small, precise components for cable management systems to ensure organization and efficiency.
• Aerospace Components:
  • Used to machine high-precision components for aircraft and spacecraft, where accuracy and consistency are paramount.
• Automotive Parts:
  • Ideal for producing parts for the automotive industry, including shafts, bushings, and custom components.
• Medical Devices:
  • Suitable for manufacturing medical device components that require high precision and stringent quality standards.
• General Machining:
  • Employed in general machining applications for creating custom parts, prototypes, and small to medium production runs.
• Tool and Die Making:
  • Used in the tool and die industry for creating precision tools, dies, and molds.

Technical Specifications:

1. Maximum Cutting Diameter:
   • Up to 16 inches (406 mm), depending on the setup and part geometry.
2. Maximum Cutting Length:
   • Up to 16 inches (406 mm), providing flexibility for a range of part sizes.
3. Spindle Speed:
   • High spindle speeds, typically up to 6,000 RPM, enabling efficient machining of various materials.
4. Tool Capacity:
   • Typically features a 12-station turret, allowing for a variety of tools to be used in a single setup.
5. Control System:
   • Equipped with Haas’ proprietary CNC control system, known for its user-friendly interface and powerful programming capabilities.

Examples of Use Cases:

1. Precision Machining:
   • Machining of high-precision aerospace components such as turbine blades and engine parts.
2. Production Runs:
   • High-volume production of automotive parts like gear blanks and axle components.
3. Medical Device Manufacturing:
   • Production of intricate medical device components such as surgical instruments and implants.

The Haas ST-10 CNC Lathe is a versatile and powerful machine that enhances the turning capabilities of any machining operation. Its combination of precision, compact design, and advanced features makes it an invaluable tool for producing high-quality turned parts across various industries.
