Adapter – Neutrik 3 Pole XLR Female to 5 Pole XLR Female Gender Conversion Adapter – NA3F5F

Price:

$37.75

PN: 21-340112 SKU 21-340112 Categories , , Tags , , , , Brand:

Unprecedented Lifetime Warranty on all the products we produce.

CALIFORNIA WARNING

Description:

Adapter – Neutrik 3 Pole XLR Female to 5 Pole XLR Female Gender Changer Adapter – NA3F5F

The Neutrik NA3F5F is a professional-grade 3-pole XLR female to 5-pole XLR female gender conversion adapter designed to reliably interconnect professional audio, lighting, broadcast, and AV systems that utilize different XLR pin configurations.

Built on Neutrik’s proven XX Series platform, this compact adapter features a rugged die-cast shell, silver-plated contacts, and a secure latch-lock mechanism for dependable performance in demanding environments.

Features & Benefits

  • 3-pole XLR female to 5-pole XLR female gender conversion adapter
  • Pre-wired and ready to use
  • Reliably interconnects various professional connector systems
  • Professional appearance based on the Neutrik XX Series
  • Compact, space-saving design
  • Rugged zinc die-cast shell for maximum reliability
  • Secure latch-lock connection
  • Ideal for audio, lighting control, broadcast, stage, and AV applications

Technical Information

Product Title NA3F5F
Connection Type Adapter
Connector Type 3-Pole XLR Female to 5-Pole XLR Female

Electrical

Contact Resistance ≤ 3 mΩ
Dielectric Strength 1.5 kVdc
Insulation Resistance > 2 GΩ
Rated Current Per Contact 3 A

Mechanical

Insertion Force < 20 N
Withdrawal Force < 20 N
Lifetime > 1000 Mating Cycles
Locking Device Latch Lock

Material

Contact Plating 2 µm Ag
Contacts Brass (CuZn39Pb3) (5-Pole Female)
Insert Polyamide (PA 6.6 30% GR)
Shell Zinc Diecast (ZnAl4Cu1)
Shell Plating Nickel

Environmental

Temperature Range -30°C to +80°C
